3 Poles ZJ19 Series 32A 220V 110 vac Coil Voltage Capacitor AC Contactor 63 amp
Product Description:
Contactor can cut off the main circuit of AC and DC quickly and is able to switch on and off the large current control circuit device frequently(up to 800A). It can be used to control the load of factory equipment, electric heater, working machine and various power sets. The contactor can not only connect and cut off the circuit, but also has the protection of low voltage release. Contactor control capacity is large, suitable for frequent operation and remote control, is one of the important components in automatic control system.
3 pole contactor is electrically controlled switches (Or relays) Which used for switching an electrical power circuit. A contactor is typically controlled by a much lower power level circuit than the switched circuit.
Main parameters and Technical Performance:
| Model | ZJ19-25 | ZJ19-32 | ZJ19-43 | ZJ19-63 | ZJ19-95 | |
| Electrical life (x1000) | 100 | 100 | 100 | 100 | 100 | |
| Rated current le (380V) A | 17 | 23 | 29 | 43 | 63 | |
| Power of controlled capacitor | 220/230V | 6 | 9 | 10 | 15 | 22 |
| 380/440V | 12 | 18 | 20 | 30 | 40 | |
| Rated insullation voltage Ui (V) | 500 | |||||
| Rated operational voltage Ue (V) | 380 | |||||
| Restrained surge capacity | 20 le | |||||
| Operation range | Pick-up: (85%～110%Us; Drop-out: (20%～75%)Us | |||||
| Coil power (VA) | Start-up | 70 | 110 | 110 | 200 | 200 |
| Holding | 8 | 11 | 11 | 20 | 20 | |
Appearance and Installation Dimension:
Installation dimension:
| Model | A max | B max | C max | D max | E | F | Note |
| ZJ19-25 | 80 | 47 | 124 | 76 | 34/35 | 50/60 | Be fixed with 35mm din rail |
| ZJ19-32 | 90 | 58 | 132 | 86 | 40 | 48 | |
| ZJ19-43 | 90 | 58 | 136 | 86 | 40 | 48 | |
| ZJ19-63 | 132 | 79 | 150 | - | - | - | Not only fixed by screws but also could be fixed with 35mm ad 75mm din rail |
| ZJ19-80～95 | 135 | 87 | 158 | - | - | - |
Packing and Delivery:
Why Choose Us:
-----------------------------------------
a. Reply your inquiry in 24 working hours.
b. Technical and professional guidance.
c. Best quality and best price.
We maintain excellent products and strive for 100% customer satisfaction. A good feedback is very important, we welcome for your kind suggestion or feedback on goods and our service.
FAQ:
1. Could I have prices of your products?
Well welcome. Please feel free to send us any inquiry. You will get our reply in 24 hours.
2. Can we print our logo/website/company name on products?
Yes, OEM and ODM are available.
3. What's the lead time for regular order?
7-15 days for order quantity less than 2000pcs. For more quantity, we can negotiate about it.
4. Do you inspect the finished products?
Our products 100% self-inspection and testing before packing.
5. How about payment terms?
30% deposit, the rest payment balance against B/L copy.
