440V AC Electric Contactor With Red Copper For Overload Industrial

100PCS
MOQ
Negotiable
Price
440V AC Electric Contactor With Red Copper For Overload Industrial
Features Gallery Product Description Request A Quote
Features
Specifications
Rated Heating Current: 50A, 60A, 80A, 100A, 110A, 135A
Number Of Poles: 3
Standard: IEC60947-4-1, GB14048.4
Auxiliary Contact: 2NC+2NO
Type: AC Contactor
Color: White
Application: AC Motor
Phase: 3
High Light:

440V AC Electric Contactor Overload Industrial

,

Red Copper AC Electric Contactor

,

Overload Industrial 440V AC Coil Contactor

Basic Infomation
Place of Origin: China
Brand Name: YOKG
Certification: CE,TUV,CB
Model Number: GC-32, GC-40
Payment & Shipping Terms
Packaging Details: Standard export packing or According to customer's demand
Delivery Time: 15days or Depends on ordering QTYS
Payment Terms: L/C, D/P, T/T
Supply Ability: 100000pcs per Month
Product Description

AC Coil 440V AC Electric Contactor With Red Copper For Overload Industrial Use



Product description:

The 440V AC Electric Contactor is suitable for using in the circuits up to the rated voltage 690V AC 50 HZ or 60 HZ , rated current up to 95A, for making, breaking, frequently starting & controlling the AC motor, Which is suitable for overload industrial use which has a red copper and 2NC+2NO Auxiliary contact.



Main parameters and Technical Performance:

Type GC-32 GC-40 GC-50 GC-65 GC-75 GC-85
Rated heating current (A) 50 60 80 100 110 135
Rated insulation voltage (V) 690
Rated impact withstand voltage (KV) 6
Rated making capacity 10le
Rated breaking capacity 8le
Poles 3
Auxiliary contact 2NC+2NO
Short-time withstand current(A) 10S 256 320 400 520 600 680
IEC-60947 AC1 Load 50 60 80 100 110 135
AC3
Load
power
200~240V 7.5KW 11KW 15KW 18.5KW 22KW 25KW
380~440V 15KW 18.5KW 22KW 30KW 37KW 45KW
500~550V 18.5KW 22KW 30KW 33KW 37KW 45KW
690V 18.5KW 22KW 30KW 33KW 37KW 45KW
AC3
Load
current
200~240V 32A 40A 55A 65A 75A 85A
380~440V 32A 40A 50A 65A 75A 85A
500~550V 28A 32A 43A 60A 64A 75A
690V 20A 23A 28A 35A 42A 45A
UL508 Continuous current 45A 50A 70A 80A 90A 100A
single-phase
machine
115V 2HP 3HP 3HP 5HP 5HP 7.5HP
230V 5HP 5HP 7.5HP 10HP 15HP 15HP
Three-phase
machine
200V 7.5HP 10HP 10HP 15HP 20HP 25HP
230V 10HP 10HP 15HP 20HP 25HP 30HP
460V 20HP 25HP 30HP 40HP 50HP 50HP
575V 20HP 25HP 30HP 40HP 50HP 50HP
Operation frequency (times/h) Electrical life 800 600
Mechanical life 3600
AC-3 Electrical life (10000/times) 80 80 60 60 60 60
Mechanical life (10000/times) 800 800 600 600 600 600




Installation dimension:

440V AC Electric Contactor With Red Copper For Overload Industrial 0



Packing and Delivery:



440V AC Electric Contactor With Red Copper For Overload Industrial 1



440V AC Electric Contactor With Red Copper For Overload Industrial 2



FAQ:

1. Could I have prices of your products?

Well welcome. Please feel free to send us any inquiry. You will get our reply in 24 hours.

2. Can we print our logo/website/company name on products?

Yes, OEM and ODM are available.

3. What's the lead time for regular order?

7-15 days for order quantity less than 2000pcs. For more quantity, we can negotiate about it.

4. Do you inspect the finished products?

Our products 100% self-inspection and testing before packing.

5. How about payment terms?

30% deposit, the rest payment balance against B/L copy.
