Detail Information

Contact Material:	Silver OR COPPER	Contact Arrangement:	1NO/1NC
Frequency Rating:	50/60Hz	Protection Level:	IP20
Current Rating:	6A,9A,12A,16A	Installation Category:	III
Rated Insulated Voltage Ui:	690V	Enclosure Material:	Plastic
Highlight:	690V 3 phase contactor , 6A motor control contactor , AC electric contactor for manufacturing

Product Description

AC Electric Contactor - 690V 3-Phase Motor Control

This highly reliable AC Electric Contactor is engineered for precise control of electrical circuits in industrial and commercial applications. With a rated insulated voltage of 690V and current ratings from 6A to 16A, it delivers exceptional performance and safety for motor control and power management systems.

Product Overview

The AC Electric Contactor features a robust plastic enclosure providing excellent insulation and environmental protection. Designed with three poles for efficient three-phase circuit control, it supports multiple coil voltage options and incorporates silver point contactor technology for superior conductivity and durability.

Key Features

Product Name: AC Electric Contactor
Type: 3 phase contactor
Contact Material: Silver or Copper
Coil Voltage Options: 24V, 36V, 48V, 110V, 220V, 230V, 240V, 380V, 400V, 415V, 440V
Installation Category: III
Ambient Temperature Range: -5℃ to +40℃
Protection Level: IP20
Designed for reliable performance in industrial applications

Technical Specifications

Frequency Rating	50/60Hz
Rated Insulated Voltage Ui	690V
Protection Level	IP20
Number of Poles	3
Contact Arrangement	1NO/1NC (NC/NO)
Contact Material	Silver or Copper (silver point contactor)
Coil Voltage	24 / 36 / 48 / 110 / 220 / 230 / 240 / 380 / 400 / 415 / 440 V
Pollution Degree	Class 3
Current Rating	6A, 9A, 12A, 16A
Enclosure Material	Plastic

Applications

The YOKG AC Electric Contactor series (models CJX2-K06, CJX2-K09, CJX2-K12, CJX2-K16) is ideal for industrial machinery, HVAC systems, automated production lines, and energy management systems. Featuring DIN rail mounting for easy installation, these contactors provide reliable switching for motor control circuits, lighting control, heating systems, and other electrical switching applications requiring precise three-phase power control.

Frequently Asked Questions

What brand manufactures the AC Electric Contactor?

The AC Electric Contactor is manufactured by the brand YOKG.

What are the available model numbers for this AC Electric Contactor?

The available model numbers are CJX2-K06, CJX2-K09, CJX2-K12, and CJX2-K16.

Where is the AC Electric Contactor produced?

This product is made in China.

What is the minimum order quantity for the YOKG AC Electric Contactor?

The minimum order quantity is 500 units.

What payment terms does YOKG accept for this product?

YOKG accepts payment via T/T (Telegraphic Transfer) and L/C (Letter of Credit).

Tag:

Place of Origin:	China
Brand Name:	YOKG
Certification:	CE
Model Number:	CJX2-K06,CJX2-K09,CJX2-K12, CJX2-K16

Minimum Order Quantity:	100
Packaging Details:	Each unit be packed in one individual inner box
Payment Terms:	T/T,L/C
