Product Details:
|
| Type: | DC Contactor | Electricity Type: | DC |
|---|---|---|---|
| Uninterrupted Duty: | 20A,32A,40A,50A,60A,80A,125A | OEM: | OEM Acceptable |
| Poles: | 3P+NO, 3P+NC, 3P+NO+NC | Standard: | IEC60947-4-1, GB14048.4 |
| High Light: | NO AC DC Contactor 40amp 380V,40amp AC DC Contactor 660vac,40amp 660vac dc power contactor |
||
DC Contactor 3P+NO 3P+NO+NC 20A 32A 40amp 60A 80A 125A 380V 660vac DC Operated AC Contactor
A DC contactor is one whose iron core is controlled by direct current. The load can be either DC or AC. The iron core of dc contactor is different from that of AC contactor. It has no eddy current, so it is generally made of mild steel or industrial pure iron into a round shape. Because the dc contactor attraction coil through DC, so there is no impact of the starting current, will not produce iron core violent impact phenomenon, so it has a long life, suitable for frequent start and stop occasions.
Main parameters and Technical Performance:
| Type | Rated working current (A) |
Rated heat current |
Rated working voltage |
Rated insulating voltage |
Controlled power (kW) | Number of the contacts |
||||
| le A (AC-3) | Ith (A) | Ue(A) | Ui(A) | 220V | 380V | 415V | 440V | 660V | ||
| LP1-D09 | 9 | 20 | 380V 660V |
660V | 2.2 | 4 | 4 | 4 | 5.5 | 3P+NO 3P+NC 3P+NO+NC |
| LP1-D12 | 12 | 20 | 3 | 5.5 | 5.5 | 5.5 | 7.5 | |||
| LP1-D18 | 18 | 32 | 4 | 7.5 | 9 | 9 | 9 | |||
| LP1-D25 | 25 | 40 | 5.5 | 11 | 11 | 11 | 15 | |||
| LP1-D32 | 32 | 50 | 7.5 | 15 | 15 | 15 | 18.5 | |||
| LP1-D40 | 40 | 60 | 11 | 18.5 | 22 | 22 | 30 | |||
| LP1-D50 | 50 | 80 | 15 | 22 | 25 | 30 | 33 | |||
| LP1-D65 | 65 | 80 | 18.5 | 30 | 37 | 37 | 37 | |||
| LP1-D80 | 80 | 125 | 22 | 37 | 45 | 45 | 45 | |||
| LP1-D95 | 98 | 125 | 25 | 45 | 45 | 45 | 45 | |||
Packing and Delivery:
FAQ:
1. Could I have prices of your products?
Well welcome. Please feel free to send us any inquiry. You will get our reply in 24 hours.
2. Can we print our logo/website/company name on products?
Yes, OEM and ODM are available.
3. What's the lead time for regular order?
7-15 days for order quantity less than 2000pcs. For more quantity, we can negotiate about it.
4. Do you inspect the finished products?
Our products 100% self-inspection and testing before packing.
5. How about payment terms?
30% deposit, the rest payment balance against B/L copy.
